Air compressor is the most important data parameters 1, exhaust volumeUnder the rated exhaust pressure, the volume of gas discharged by the air compressor per unit time is converted to the volume of gas in the intake state, which is the exhaust volume of the air compressor (that is, the volume flow), the unit is: m³ popular terms, the exhaust volume of the air compressor refers to the number of cubic meters of air inhaled by the machine intake port per minute, not the number of cubic meters of compressed air discharged by the machine exhaust port per minute. 2.Exhaust pressureThe exhaust pressure of the air compressor refers to the gas pressure that is finally discharged from the compressor, and the unit is: Mpa. Air compressor industry commonly used “kg” as a pressure unit, 1 kg =0.1Mpa.The exhaust pressure on the air compressor name tag is called the rated exhaust pressure, and it is also the maximum exhaust meter pressure allowed by the compressor. Exhaust volume and exhaust pressure are two very important parameters of air compressor. 3. air compressor exhaust temperatureAir compressor exhaust temperature refers to the temperature of the air discharged from the exhaust port of the main…

Air compressor small class Air compressor as an important form of energy generationIt is widely used in all aspects of productionBecome an indispensable machine for social developmentFaced with such commonly used equipmentWhat should we know? Basic theoretical knowledge of air What is air? What is normal air? The atmosphere around the earth, we are used to calling it air. The air with a pressure of 0.1MPa, a temperature of 20 ° C, and a relative humidity of 36% is normal air. Normal air differs from standard air in that it is warm and contains moisture. When there is water in the air, once the water is separated, the volume of gas will be reduced. What is the standard state definition of air?The definition of the standard state is: the air state when the air suction pressure is 0.1MPa and the temperature is 15.6 ° C (the domestic industry definition is 0 ° C) is called the standard state of the air.In the standard state, the air density is 1.185kg/m³(the processing capacity of air compressor displacement, dryer, filter and other post-processing equipment is marked by the flow rate under the air standard state, and the unit is written as Nm³/min). What…
